Used Industrial Robot
FANUC
M-20iA/20T
High-Inertia Compact 6-Axis Robot
Overview
FANUC M-20iA/20T
The FANUC M-20iA/20T is a toploader-optimized variant of the M-20iA platform, configured for overhead rail mounting with a 20 kg payload and 1,661 mm reach. The T-suffix designates an arm geometry and J1-J2 motion envelope that is optimized for loading operations from above — reaching down into machine tools, presses, or fixtures below the rail track rather than the floor-based geometry of the standard M-20iA. Toploader configurations reduce the floor footprint of machine-tending cells by mounting the robot overhead rather than beside the machine.
The M-20iA/20T shares the M-20iA’s hollow arm cable routing architecture, with utilities routed internally to protect dress packs from the coolant and swarf exposure common in machine tending environments. The overhead mounting configuration naturally positions the robot’s dress pack away from coolant spray and chip accumulation at the machine tool spindle level. The sealed joint construction provides additional protection appropriate for CNC machine tending duty.
Compatible with the R-30iB controller in the B-size cabinet with iPendant Touch, the M-20iA/20T supports the full FANUC software suite including iRVision for part orientation detection, Collision Guard for protection when entering machine tool envelopes, and servo soft float for compliant part seating. ROBOGUIDE simulation with the correct toploader mounting orientation is strongly recommended for cell layout verification prior to installation.
iGAM offers the M-20iA/20T at multiple condition levels depending on your application and budget. All units are inspected and run prior to shipping from our Detroit facility. For customers requiring higher confidence, our reconditioning service brings the robot through a documented multi-stage process covering axis lubrication, servo evaluation, controller servicing, and functional testing. iGAM also works with customers who own a M-20iA/20T and need maintenance or refurbishment performed — bringing an existing robot back to reliable operation rather than replacing it outright.
Key Specifications
Payload20 kg
Reach1,661 mm
Axes6
Repeatability0.08 mm
Robot Weight185 kg
MountingFloor
Inventory
Available FANUC M-20iA/20T Units
Specifications
Full Technical Specifications
| General Specifications | |
| Controlled Axes | 6 |
| Structure | Articulated |
| Mounting Options | Floor |
| Payload | 20 kg |
| H-Reach | 1661 mm |
| Repeatability | ±0.08 mm |
| Robot Weight | 185 kg |
| Technical Details | |
| Body Protection Class | IP54 (IP55 optional) |
| Wrist & J3 Protection | IP67 |
| Compatible Controllers | R-30iB |
| Cabinet Size Options | B-cabinet |
| Teach Pendant Options | iPendant Touch |
| Motion Range | |
| J1 Motion Range | ±185° |
| J2 Motion Range | ±300° |
| J3 Motion Range | ±586° |
| J4 Motion Range | ±400° |
| J5 Motion Range | ±360° |
| J6 Motion Range | ±900° |
| Maximum Speed | |
| J1 Max Speed | 195°/s |
| J2 Max Speed | 175°/s |
| J3 Max Speed | 180°/s |
| J4 Max Speed | 360°/s |
| J5 Max Speed | 360°/s |
| J6 Max Speed | 550°/s |
Applications
Common Applications
The FANUC M-20iA/20T is well-suited for a range of industrial automation applications. Select the application below most relevant to your production needs.
Assembly
Precision part fitting, fastening, and sub-assembly operations.
Material Handling
High-speed pick, place, and transfer of parts between production cells.
Machine Tending
Automated load and unload of CNC machining centers, presses, and injection molds.
Packaging
Case packing, carton erecting, and end-of-line packaging automation.
Why iGAM
The iGAM Difference
Inspected & Tested
Every robot is powered on and run through full axis testing before it ships. No surprises on arrival.
Warranty Available
90-day standard warranty on reconditioned units. Extended coverage available on select inventory.
Freight Assistance
In-house crating and freight coordination from our Detroit warehouse. We ship nationwide.
Expert Support
Talk directly to a robot specialist — not a call center. We know the equipment we sell.
Ready to source a FANUC M-20iA/20T?
Our team typically responds within one business day with availability and pricing.
