WEG 00118ET3E1437-W22 1HP 3PH AC Motor 143/5T Frame 208-230/460V NEW 0
WEG 00118ET3E1437-W22 1HP 3PH AC Motor 143/5T Frame 208-230/460V NEW 1
WEG 00118ET3E1437-W22 1HP 3PH AC Motor 143/5T Frame 208-230/460V NEW 2
WEG 00118ET3E1437-W22 1HP 3PH AC Motor 143/5T Frame 208-230/460V NEW 4

SOLD!

WEG 00118ET3E1437-W22 1HP 3PH AC Motor 143/5T Frame 208-230/460V NEW

$275.00
Availability:

1 in stock
BRAND: WEG MODEL: 00118ET3E1437-W22 CONDITION: new
SKU: IGAM3470158 Weight: 47 lbs Shipping Calculated at Checkout

1 in stock

Make an offer

Overview

This listing is for a NEW WEG 00118ET3E1437‑W22. Three-phase AC induction motor configured for general industrial duty, operating at dual voltage with 1 HP output and a 143/5T frame, supporting continuous operation in plant and machinery applications.

Specification Table

Manufacturer: WEG Model/Series: W22 Part Number: 00118ET3E1437-W22 Condition: NEW YOM: n/a Motor Type: AC Induction Motor (3-Phase) Efficiency Rating: NEMA Premium Horsepower: 1 HP Frequency: 60 Hz Speed: 1730 RPM (nominal) Voltage: 208-230 / 460 VAC Full Load Current: 3.46 / 1.73 A Phase: 3 Phase Service Factor: 1.25 Power Factor: 0.76 Frame Size: 143/5T Enclosure: TEFC (Totally Enclosed Fan Cooled) Protection Rating: IP55 Insulation Class: F Temperature Rise: Class B Duty Cycle: Continuous (S1) Ambient Temperature: 40°C Altitude Rating: 1000 m Efficiency: ~85.5% Mounting: Foot-mounted (standard NEMA) Connection Diagram: 208-230/460V 9-lead configuration (T1-T9) Weight: 44 lb
