TIMKEN 98350-70000 Tapered Roller Bearing Cone NEW

Specification Table

IDENTIFICATION Manufacturer: TIMKEN Part Number: 98350-70000 Cone Number: 98350 Bearing Type: Single Cone Tapered Roller Bearing Condition: NEW UPC: 0053893457680 YOM: n/a   DIMENSIONS Bore Diameter (d): 3.5000 in Bore Diameter (d): 88.9 mm Inner Ring Width (B): 1.9375 in Inner Ring Width (B): 49.213 mm Effective Center Location: 0.05 in Effective Center Location: 1.3 mm   LOAD RATINGS Dynamic Radial Load Rating (C1): 108,000 lbf Dynamic Radial Load Rating (C1): 482,000 N Dynamic Radial Load Rating (C90): 28,100 lbf Dynamic Radial Load Rating (C90): 125,000 N Dynamic Axial Load Rating (Ca90): 30,400 lbf Dynamic Axial Load Rating (Ca90): 135,000 N Static Radial Load Rating (C0): 117,000 lbf Static Radial Load Rating (C0): 519,000 N   BEARING DATA Bearing Design: Single Row Tapered Roller Number of Rollers Per Row: 18 K Factor: 0.92 G1 Factor: 203.4 G2 Factor: 37.5 Geometry Factor (Cg): 0.120   INSTALLATION DATA Maximum Shaft Fillet Radius: 0.140 in Maximum Shaft Fillet Radius: 3.600 mm Shaft Shoulder Diameter Frontface (da): 4.41 in Shaft Shoulder Diameter Frontface (da): 112 mm Shaft Shoulder Diameter Backface (db): 4.65 in Shaft Shoulder Diameter Backface (db): 118 mm Cage Location Relative to Backface (Aa): 0.31 in Cage Location Relative to Backface (Aa): 7.9 mm Cage Location Relative to Frontface (Ab): 0.24 in Cage Location Relative to Frontface (Ab): 6.1 mm   APPLICATION DATA Combined Radial & Thrust Loading: Yes Industrial Gearboxes: Yes Power Transmission Equipment: Yes Heavy Machinery: Yes Material Handling Equipment: Yes Rotating Shaft Assemblies: Yes
