TIMKEN 56650 Tapered Roller Bearing Cup NEW

Specification Table

IDENTIFICATION Manufacturer: TIMKEN Model: 56650 Bearing Type: Tapered Roller Bearing Cup Component Type: Cup Condition: NEW Country of Manufacture: USA UPC: 0053893338590 DIMENSIONS Outside Diameter (D): 6.5000 in Outside Diameter (D): 165.1 mm Outer Ring Width (C): 1.0625 in Outer Ring Width (C): 26.988 mm BEARING DATA Bearing Design: Single Row Tapered Roller Component Configuration: Cup Load Type: Combined Radial and Thrust INSTALLATION DATA Maximum Housing Fillet Radius: 0.130 in Maximum Housing Fillet Radius: 3.3 mm Housing Backing Shoulder Diameter - Frontface (Da): 6.30 in Housing Backing Shoulder Diameter - Frontface (Da): 160.00 mm Housing Backing Shoulder Diameter - Backface (Db): 5.87 in Housing Backing Shoulder Diameter - Backface (Db): 149.10 mm FACTORS e Factor: 0.5 Y Factor: 1.21 Geometry Factor (Cg): 0.158 PHYSICAL DATA Weight: 5.8 lb Weight: 2.6 kg APPLICATION DATA Industrial Gearboxes: Yes Power Transmission Equipment: Yes Material Handling Equipment: Yes Heavy Machinery: Yes Mobile Equipment: Yes Rotating Shaft Assemblies: Yes
