TB WOODS 6E EPDM Sure-Flex Plus Coupling Sleeve 2-Piece with Retaining Ring NEW

$12.50
Availability:

Out of stock

BRAND: TB WOODS MODEL: 6E EPDM CONDITION: used
SKU: IGAM1980374 Weight: 1 lbs Shipping Calculated at Checkout

Out of stock

Overview

This listing is for a NEW TB WOODS 6E EPDM. It is designed for flexible shaft coupling in industrial power transmission systems. This unit is categorized as a Sure-Flex Plus Coupling Sleeve and includes the following capabilities: 6000 RPM max speed, 585 in-lb torque, and 4-way flexing action.

Specification Table

Manufacturer: TB Wood’s (Regal Rexnord)
Part Number: 6E EPDM
Model: Sure-Flex Plus
Condition: NEW
Function: Elastomeric Coupling Sleeve
Compatibility: Sure-Flex Plus Flanges
Mounting: 2-Piece with Retaining Ring
Material: EPDM Rubber
Max Speed: 6000 RPM
Torque Capacity: 585 in-lb (66 Nm)
Outside Diameter: 3.75 in (95.25 mm)
Width: 1.875 in (47.63 mm)
Parallel Misalign.: 0.015 in
Angular Misalign.: 1°
Temperature Range: -30°F to 275°F
Weight: 0.49 lb (0.22 kg

▸ Key Features:
• 2-piece EPDM sleeve with retaining ring
• Rated for up to 6000 RPM
• 585 in-lb torque capacity
• 4-way flexing action absorbs shock and misalignment
• Maintenance-free, no lubrication required
▸ Applications:
• Pumps and compressors
• Fans and blowers
• Conveyors and mixers
• General industrial drive systems
▸ Alternative Model Numbers:
6E
6E EPDM
TBW-6E
6E-SF-EPDM
6E-EPDM-SLEEVE
▸ Common Misspellings or Phrasing:
TB Woods 6E Sleeve
6E Coupling Insert
6E Elastomer Sleeve
TBW 6E EPDM
SureFlex 6E EPDM
