Specification Table
Manufacturer: SMC
Product Line: Slim Line Power Clamp
Series: CKZ1
Part Number: CKZ1N63-105LX16-7USB-AA032
Condition: NEW
YOM: n/a
General Information:
Component Type: Pneumatic power clamp
Primary Application Role: Workpiece clamping in automated fixture systems
Intended Use: Industrial automation, CNC machining, OEM equipment
Mechanical / Functional:
Clamp Style: Slim line power clamp
Actuation Type: Pneumatic
Mounting Style: Fixture-mounted
Clamp Operation: Automated clamping mechanism
Configuration:
Bore Size: 63 mm
Stroke / Arm Configuration: Application-specific
Sensor Provision: Not specified
Pneumatic:
Operating Medium: Compressed air
Maximum Pressure: 0.80 MPa
Compatibility:
System Integration: Industrial automation and CNC fixture systems
Interchange / Fitment: Match CKZ1N63-105LX16-7USB-AA032 for direct replacement
Included:
Includes: Power clamp unit as packaged by SMC
Cosmetic Condition:
New, unused; original packaging present
Product Specifications
- Model Number: CKZ1N63-105LX167USB AA032
- Clamp Type: Slim Line Power Clamp
- Clamp Bore Size: 63mm
- Stroke Length: 105mm
- Operating Pressure Range: 0.1 to 1.0 MPa
- Mounting Type: Universal Side and Bottom Mounting
- Sensor Compatibility: USB sensor connection for precise position detection
- Material: High-strength aluminum alloy with stainless steel components
- Port Size: Standard pneumatic fittings
- Temperature Range: -10°C to 60°C
Key Features
- Slim, Compact Design – Optimized for space-saving applications in automated systems.
- High Clamping Force – Delivers robust performance for securing components in manufacturing.
- USB Sensor Connection – Enables accurate position detection for precision control.
- Durable Construction – Made from high-strength aluminum alloy for long service life.
- Versatile Mounting Options – Supports multiple installation configurations for easy integration.
- Smooth Pneumatic Operation – Provides consistent and efficient clamping performance.
Applications
- Automated Assembly Lines – Ideal for securing components during robotic assembly processes.
- Welding Fixtures – Used to hold metal parts in place for precision welding applications.
- Material Handling Systems – Provides stable clamping for workpieces in conveyor and robotic handling.
- Automotive Manufacturing – Ensures precise alignment and positioning in car assembly.
- Industrial Automation – Enhances efficiency and repeatability in automated processes.
Alternative Model Numbers Include:
CKZ1N63-105L-USB-AA032, CKZ1N63-105LX167-AA032, CKZ1N63-105LX167USB-AA031, CKZ1N63-105LX167USB-AA033, CKZ1N63-105LX167USB-AA034
Common Misspellings Include:
SMC CKZIN63-105LX167USB AA032, CKZ163-105LX167USB AA032, CKZ1N63-105LX167US8 AA032, SMC CKZ1N63-105LX167UB AA032, CKZ1N63-105LX167USB-AA032
