SIEMENS 3RV2921-1M Auxiliary Switch Block 2NO 2NC USED

Specification Table

IDENTIFICATION Manufacturer: Siemens Part Number: 3RV2921-1M Product Type: Auxiliary switch block Contact Configuration: 2 NO + 2 NC Condition: USED YOM: n/a Country of Manufacture: Czech Republic   FUNCTION / COMPATIBILITY Primary Function: Auxiliary switching / signaling Compatible Device Families: 3RV2 / 3RV1.1 Contact Function: Status feedback / control circuitry   CONTACT CONFIGURATION Contact 57-58: NO Contact 65-66: NC Contact 77-78: NO Contact 85-86: NC Total NO Contacts: 2 Total NC Contacts: 2   ELECTRICAL Rated Insulation Voltage Ui: 690 V Impulse Withstand Voltage Uimp: 6 kV   UTILIZATION RATINGS DC-13 at 24 VDC: 2 A DC-13 at 220/230 VDC: 0.25 A DC-13 at 690 VDC: Not rated   AC-15 at 24 VAC: 6 A AC-15 at 220/230 VAC: 4 A AC-15 at 690 VAC: 1 A   AC-12 at 24 VAC: 10 A AC-12 at 220/230 VAC: 10 A AC-12 at 690 VAC: 10 A   CONNECTION / INSTALLATION Mounting Type: Side-mounted accessory Terminal Type: Screw terminals Conductor Range: AWG 20 to AWG 14 Conductor Material: Copper Conductor Temperature Rating: 75 °C   STANDARDS / APPROVALS IEC Standard: IEC 60947-5-1 GB/T Standard: GB/T 14048.5 CE Marking: Present UKCA Marking: Present CCC Marking: Present UL Listing: Listed UL Classification: Industrial Control Equipment UL Marking: 165C   GENERAL-USE RATING General-Use Current: 10 A General-Use Voltage: 240 VAC
