SIEMENS 3RV2021-4BA10 with 3RT2026-1BB40 SIRIUS Motor Starter Combination USED

Specification Table

IDENTIFICATION Manufacturer: Siemens Product Family: SIRIUS Product Type: Motor starter combination Condition: USED YOM: n/a   MOTOR PROTECTION CIRCUIT BREAKER Part Number: 3RV2021-4BA10 Device Type: Motor protection circuit breaker Number of Poles: 3 Adjustment Range: 13 to 20 A Trip Class: Class 10 Instantaneous Trip Marking: 260 A Operating Control: Rotary Operating Positions: ON / OFF / TRIPPED Test Function: Present Line Terminals: 1/L1, 3/L2, 5/L3 Load Terminals: 2/T1, 4/T2, 6/T3 Terminal Torque: 2 to 2.5 Nm Ambient Temperature Range: -20 to +60 °C   CONTACTOR Part Number: 3RT2026-1BB40 Device Type: Three-pole power contactor Main Poles: 3 Coil Voltage: 24 VDC Coil Type: DC Coil Terminals: A1 / A2 Auxiliary Contacts: 1 NO + 1 NC NO Auxiliary Contact: 13-14 NC Auxiliary Contact: 21-22 Line Terminals: 1/L1, 3/L2, 5/L3 Load Terminals: 2/T1, 4/T2, 6/T3   STARTER CONFIGURATION Protection Device: 3RV2021-4BA10 Switching Device: 3RT2026-1BB40 Protection Adjustment: 13 to 20 A Contactor Control Voltage: 24 VDC Main Circuit: Three-pole Interconnection: Direct device-to-device configuration   CONNECTION / INSTALLATION Main Terminal Type: Screw Control Terminal Type: Screw Field Wiring: Present Control Wiring: Present Installation Format: Modular motor-control configuration   MARKINGS / APPROVALS CE Marking: Present UKCA Marking: Present ATEX Marking: Present IECEx Marking: Present
