REPUBLIC MANUFACTURING RBX250 Centrifugal Blower 30 HP NEW

Specification Table

HP	30 HP
RPM	3525
Frame	286TSC
Phase	3
Voltage	230/460

IDENTIFICATION Manufacturer:               Republic Manufacturing Model:                      RBX250 Product Type:               Centrifugal Blower Serial Number:              040416683 Condition:                  NEW YOM:                        n/a AIRFLOW PERFORMANCE Operating Mode:             Vacuum / Pressure Maximum Flow (60 Hz):       2470 CFM Maximum Flow (60 Hz):       4197 m³/hr Maximum Vacuum (60 Hz):     88 in.H2O Maximum Vacuum (60 Hz):     219 mbar Maximum Pressure (60 Hz):   105 in.H2O Maximum Pressure (60 Hz):   262 mbar Peak Efficiency:            80% Sound Level:                89 dB BLOWER SYSTEM Drive Configuration:        Belt Driven Belt Type:                  Poly-V Belt Discharge Configuration:    Rotatable Bearing Type:               Ceramic Hybrid Bearings Seal Design:                Two-Piece Labyrinth Seal Impeller Assembly:          Precision Balanced Housing Material:           Aluminum Bearing Housing:            Removable FILTRATION SYSTEM Quick-Release Filter:       Installed Intake Filter Assembly:     Installed Primary Filter Element:     Installed Spare Filter Element:       Included Air Intake Protection:      Installed MOTOR & DRIVE Motor Manufacturer:         Baldor Reliance Motor Series:               Super-E Motor Catalog Number:             CEM4108T Specification Number:       10E346Z501G1 Horsepower:                 30 HP Speed:                      3525 RPM Voltage:                    230/460 VAC Phase:                      3 Phase Frequency:                  60 Hz Current Rating:             68/34 A Frame Size:                 286TSC Insulation Class:           Class F NEMA Design:                Design B Service Factor:             1.15 Ambient Rating:             40°C Power Factor:               90% CONNECTIONS Inlet Connection:           Industrial Flanged Discharge Connection:       Industrial Flanged Reducer Transition:         Included Connection Hardware:        Included CONSTRUCTION Mounting Configuration:     Foot Mounted Machine Configuration:      Horizontal Protective Guarding:        Installed CE Marked:                  Yes
