Pneumatic Dual-Station Flip Fixture / Machine Base Table USED

Specification Table

IDENTIFICATION Manufacturer: Not specified Model / Part Number: Not specified Product Type: Dual-station flip fixture Condition: USED YOM: n/a FIXTURE CONFIGURATION Number of Fixture Stations: 2 Fixture Function: Workpiece positioning / reorientation Fixture Motion: Pivoting Fixture Platforms: 2 Platform Construction: Machined metal Fixture Stations: Independently configured Mounting Hole Patterns: Present Specific Workpiece Tooling: Not specified PIVOT SYSTEM Pivot Shafts: Present Bearing Supports: Pillow block style Bearings per Pivot Shaft: 2 Shaft Retention Hardware: Present Fixture Rotation: Present Rotation Angle: Not specified Position Stops: Present PNEUMATIC SYSTEM Actuation Type: Pneumatic Pneumatic Hardware: Present Pneumatic Connections: Present Actuation Configuration: Fixture integrated Operating Pressure: Not specified Actuator Manufacturer: Not specified Actuator Model: Not specified FIXTURE PLATES Fixture Plate Material: Metal Fixture Plate Finish: Machined Tapped / Drilled Holes: Present Replaceable Tooling: Not specified Fixture Plate Dimensions: Not specified UTILITY MANAGEMENT Cable Carrier: Present Utility Routing Openings: Present Through-Table Routing: Present Field Connections: Present MACHINE BASE Base Type: Fabricated machine table Frame Construction: Welded structural steel Tabletop: Heavy steel plate Fixture Mounting Surface: Drilled / machined Floor Mounting Feet: 4 Floor Anchor Provisions: Present Forklift Pockets: 2 Lower Frame: Open structural design INSTALLATION Installation Type: Floor mounted Station Arrangement: Side-by-side Machine Integration: Production / automation equipment / robotic welding Service Access: Open-frame base
