MOOG G404-543A G400 Series Brushless Servomotor 1.1kW USED

Name: MOOG G404-543A G400 Series Brushless Servomotor 1.1kW USED
Brand: MOOG
SKU: IGAM2850037
Price: 175 USD
Availability: InStock

$175.00

Availability:

1 in stock

BRAND: MOOG MODEL: G404-543A CONDITION: Used

SKU: IGAM2850037 Weight: 8 lbs Shipping Calculated at Checkout

1 in stock

Make an offer

Overview

This listing is for a USED Moog G404-543A brushless servomotor. The G400 Series is designed for high-performance motion control applications requiring precise speed, torque, and positioning control. This unit features a 1.1 kW power rating, 5500 RPM rated speed, IP65 protection, and Class F insulation for industrial automation and servo drive systems.

Description
Tags

Specification Table

Manufacturer: Moog Series: G400 Series Part Number: G404-543A Type: G-4-M4-055-06-04-01-02 Serial Number: N222 Condition: USED Equipment Type: Brushless Servomotor Output Power: 1.1 kW Rated Speed: 5500 RPM Continuous Torque: 2.6 Nm Continuous Current: 6.3 Arms DC Bus Voltage: 325 VDC Motor Constant (Ke): 0.35 Vpk/rad/s Rotor Inertia: 1.55 kgcm² Ingress Protection: IP65 Insulation Class: Class F Duty Rating: S1 Standards: IEC34 Standards: NEMA MG7 Standards: VDE-0530 Country of Manufacture: India YOM: 2016
