IAI ISB-MXM-WA-100-20-300-T2-A1S-AQ Electric Actuator 300mm Stroke NEW

Specification Table

IDENTIFICATION Manufacturer: IAI Corporation Series: ISB-MXM Model: ISB-MXM-WA-100-20-300-T2-A1S-AQ Serial Number: B10379303 Condition: NEW YOM: 2021 Country of Origin: Japan ACTUATOR Product Type: Electric Actuator Actuator Type: Slider Type Encoder Type: Battery-less Absolute Motor Output: 100 W MOTION Stroke Length: 300 mm Lead: 20 mm PERFORMANCE Positioning Repeatability: ±0.01 mm Payload Capacity (Horizontal): 25 kg Payload Capacity (Vertical): 6 kg Rated Thrust: 106 N Maximum Speed: 1200 mm/s MECHANICAL Drive Method: Ball Screw Dynamic Allowable Load Moment Ma: 58 N·m Mb: 83 N·m Mc: 136 N·m Dynamic Straightness: 0.02 mm/m Max ELECTRICAL Input Voltage: 200-230 VAC Phase: 3 Phase Frequency: 50/60 Hz PROTECTION IP Rating: IP40 Protection Scope: Live Part Only CONFIGURATION Applicable Controller: T2 Cable Exit Direction: A1S AQ Seal: Included CONSTRUCTION Base Material: Aluminum Surface Finish: White Alumite Treatment ENVIRONMENTAL Operating Temperature: 0°C to 40°C Humidity: 85% RH Max (Non-Condensing) PHYSICAL DATA Actuator Length: 579 mm Weight: 4.5 kg
