FANUC M-16IB/20 ROBOT + R-J3IB CONTROLLER USED

$5,750.00
Availability:

1 in stock
BRAND: FANUC MODEL: M-16IB/20+R-J3IB CONDITION: used
SKU: IGAM1300015 Weight: 1000 lbs Freight (Item Must Ship Freight)

1 in stock

Make an offer
Get Shipping Quote

Overview

The FANUC M-16iB/20 Robotic Arm with R-J3iB Controller is a used high-precision, six-axis automation solution designed for dynamic industrial applications such as material handling, machine tending, and assembly. With a 20 kg payload and a generous 1,667 mm reach, the M-16iB/20 is ideal for operations requiring both strength and flexibility. Its slim, double-jointed arm allows for extended reach in tight workspaces, while maintaining high-speed, repeatable motion. The system is driven by the R-J3iB controller, known for its stable platform, multi-tasking capability, and user-friendly programming interface. Whether used in high-mix/low-volume production or repetitive high-volume tasks, this robotic system offers robust performance, long-term reliability, and easy integration with other FANUC automation technologies. Perfect for manufacturers seeking a cost-effective way to enhance productivity, improve precision, and reduce cycle times.

Product Specifications:

  • Robot Arm:

    • Model: M-16iB/20

    • Axes: 6

    • Payload Capacity: 20 kg

    • Reach: 1,667 mm

    • Repeatability: ±0.08 mm

    • Mounting Options: Floor, inverted, angle

    • Mass: Approximately 220 kg

  • Controller:

    • Model: R-J3iB

    • Control Capacity: Capable of managing up to 16 FANUC motor-based axes simultaneously

    • Variants: Available in A-cabinet, B-cabinet, and Mate-cabinet styles to accommodate different robot sizes and applications



Key Features:

  • Enhanced Work Envelope: The M-16iB/20’s “double-jointed” arm design increases its work envelope and positioning flexibility, allowing it to handle large parts within its reach.

  • Advanced Motion Control: The R-J3iB controller offers improved motion dynamics and application performance over its predecessors, enhancing operational efficiency.

  • Versatile Mounting: Multiple mounting options, including floor, inverted, and angle positions, provide flexibility in integration into various production environments.

  • High-Speed Operation: The robot’s axes offer substantial motion speeds, with J1 and J2 at 165°/s, J3 at 175°/s, J4 at 350°/s, J5 at 340°/s, and J6 at 520°/s, facilitating efficient task execution.



Applications:

  • Material Handling: Efficiently transports components and products between processes.

  • Assembly Operations: Performs precise assembly tasks in manufacturing settings.

  • Dispensing: Suitable for applications requiring accurate dispensing of materials.

  • Additive Manufacturing: Can be integrated into 3D printing and additive manufacturing processes.



Alternative model numbers include: FANUC M-16iB, M-16iB/20, FANUC M-16iB/20 R-J3iB

Common misspellings include: FANUC M16iB/20, FANUC M-16IB/20, FANUC M-16iB20, FANUC M-16iB/2O
