Carrier WeatherMaker 50TCQD14A2A6A0A0G0 12.5 Ton Heat Pump Rooftop Unit NEW

Specification Table

Manufacturer: Carrier Corporation Series: WeatherMaker Model: 50TCQD14A2A6A0A0G0 Condition: NEW YOM: 2022 Equipment Type: Packaged Rooftop Heat Pump Cooling Capacity: 142,000 BTU/hr Cooling Capacity (Tons): 12.5 Ton Cooling Capacity (kW): 41.5 Heating Type: Heat Pump (Reverse Cycle) Heating Capacity: 142,000 BTU/hr Refrigerant Type: R-410A Refrigeration Circuits: 2 Compressor Quantity: 2 Fan Type: Axial Condenser Fans Nominal Voltage: 460 VAC Phase: 3 Phase Frequency: 60 Hz Minimum Circuit Ampacity (MCA): 118 A Maximum Overcurrent Protection: 183 A Short Circuit Rating: 5 kA RMS Symmetrical Control Voltage: 24 VAC Design Pressure High Side: 650 PSIG Design Pressure Low Side: 506 PSIG Airflow Configuration: Horizontal Ducted Supply / Top Discharge Condenser Cabinet Construction: Outdoor Packaged Steel Enclosure Certification: AHRI Certified, ETL Listed Function: Packaged heat pump system providing heating and cooling for commercial buildings
