Bosch Rexroth R036050000 CKK-145-NN-1 Compact Module USED

Specification Table

IDENTIFICATION -------------- Manufacturer: Bosch Rexroth Product Family: Compact Module Model: CKK-145-NN-1 Part Number: R036050000 Condition: USED YOM: n/a FUNCTION -------- Motion Type: Linear Motion Drive Type: Ball Screw Assembly Guide System: Ball Rail System Configuration: Compact Module Positioning Method: Precision Linear Positioning CONSTRUCTION ------------ Frame Material: Aluminum Profile Guideway Type: Integrated Ball Rail Guides Carriage Style: Integrated Carriage Module Design: Ready-to-Install Linear Axis MECHANICAL ---------- Size Designation: 145 Maximum Standard Module Length: 1800 mm Repeatability: Up to ±0.005 mm Dynamic Guide Load Capacity: 76,025 N Dynamic Ball Screw Load Capacity: 15,480 N Dynamic Fixed Bearing Load Capacity: 17,000 N LOAD CAPACITY ------------- Dynamic Torsional Moment Capacity: 3,345 Nm Dynamic Longitudinal Moment Capacity: 3,801 Nm Maximum Dynamic Moment Mx: 1,267 Nm Maximum Dynamic Moment My: 1,440 Nm Maximum Dynamic Moment Mz: 683 Nm Maximum Fy Load: 13,660 N Maximum Fz1 Load: 28,800 N Maximum Fz2 Load: 28,800 N DIMENSIONS ---------- Profile Width (A): 145 mm Profile Height (H): 65 mm Overall Height (H1): 85 mm Carriage Length (Connection Plate Version): 190 mm ENVIRONMENTAL ------------- Mechanical System Operating Temperature: -10°C to 60°C
