APEX DYNAMICS LUG-411 Smart Lubrication System NEW

Specification Table

IDENTIFICATION Manufacturer: Apex Dynamics, Inc. Model: LUG-411 Serial Number: 140525L00019 Condition: NEW Country of Origin: Taiwan LUBRICATION SYSTEM Product Type: Smart Lubrication System Lubrication Method: Automatic Grease Lubrication Outlet Configuration: Single Outlet Outlet 1.1 Delivery: 0.15 cm³ Per Stroke Grease Delivery: 0.30 cm³ Per Cycle CONTROL Control Modes: PLC Mode 0 Timer Mode 1 PLC Mode 2 Status Output: 1 Set Command Input: 1 Set ELECTRICAL Input Power: 24 VDC ±4% Power Consumption: 12 W Max Operating Current: ≤500 mA Status Output Current: 100 mA Max Command Input Current: 50 mA Max ENVIRONMENTAL Operating Temperature: -25°C to +70°C CONNECTIONS 5-Pin Power Connector: Present 6-Pin Hand-Set Connector: Present Grease Outlet Thread: M6 INSTALLATION Mounting Hardware: 2 x M6 Screws 2 x Washers Recommended Tightening Torque: 5 Nm CONSTRUCTION Grease Cartridge: Integrated Industrial Duty: Yes CERTIFICATIONS CE Marked: Yes
