ALLEN BRADLEY PLC INPUT AND OUTPUT MODULE USED

Product Specifications

• Model Number: 1734-IB4D
• Type: Digital DC Input Module with Diagnostics
• Number of Inputs: 4 Points
• Input Voltage: 24V DC (Sink)
• Input Current: 2 mA per channel at 24V DC
• Diagnostic Features: Fault detection for wiring and system errors
• Isolation Voltage: 50V (continuous)
• Operating Temperature: 0°C to 55°C (32°F to 131°F)
• Mounting Type: DIN Rail
• Condition: Used

Key Features

• Integrated Diagnostics: Provides real-time feedback on wiring and system faults for efficient troubleshooting.
• Space-Saving Design: Compact module ideal for installations with limited space.
• LED Indicators: Offers visual status updates for each input channel and diagnostic conditions.
• Durable Construction: Engineered for reliable performance in demanding industrial settings.
• Plug-and-Play Integration: Simplifies setup and reduces installation time.

Applications

• Industrial Automation: Monitors input signals from sensors, switches, and other devices in manufacturing systems.
• Process Control Systems: Ideal for industries like food and beverage, pharmaceuticals, and chemical processing.
• Material Handling Systems: Ensures smooth operation in conveyors, sorters, and automated systems.
• Machine Building: Enhances scalability and modularity in machine designs.
• System Upgrades: Perfect for adding input capabilities to existing POINT I/O configurations.

 Alternative model numbers include: 1734IB4D, 1734-IB4D/A, 1734-IB4D Series C, 1734-IB4-D, 1734-IB4D-D.Common misspellings include: 1734-1B4D, 1734IB-4D, 1734-B4D, 1734-I-B4D, and 1734IB4-D.
