ALLEN-BRADLEY MPL-B4530K-MJ74AA MP-Series 480V AC Rotary Servo Motor NEW

Specification Table

Torque (Nm)	8.25 NM / 20.3 NM
Max Speed	4000 RPM

IDENTIFICATION Manufacturer: Allen-Bradley Series: Kinetix MPL Model: MPL-B4530K Part Number: MPL-B4530K-MJ74AA Product Number: PN-12275 Serial Number: 91321674 Series Revision: A Condition: NEW YOM: 2021 Country of Origin: Mexico MOTOR PERFORMANCE Rated Output: 2.6 kW Rated Speed: 4000 RPM Maximum Speed: 4000 RPM TORQUE Continuous Stall Torque: 8.25 Nm Peak Stall Torque: 20.3 Nm ELECTRICAL Voltage Class: 400/480 VAC Motor Technology: Brushless AC Synchronous Servo FEEDBACK Encoder Type: Absolute Encoder Feedback Protocol: Hiperface Smart Motor Technology: Yes MECHANICAL Rotor Inertia: 0.00040 kg·m² Motor Weight: 7.3 kg Frame Size: 130 mm Stack Length: 30 CONSTRUCTION Motor Series: Low Inertia Servo Motor Rare Earth Magnets: Yes Mounting Standard: IEC Environmental Rating: IP50 Minimum IP66 With Optional Shaft Seal: Yes CERTIFICATIONS UL Recognized: Yes CE Marked: Yes
