SICK 1018651 C4000 Advanced Safety Light Curtain Sender NEW

Specification Table

IDENTIFICATION Manufacturer: SICK Product Line: C4000 Advanced Model: C40S-1503CA010 Part Number: 1018651 Device Type: Safety Light Curtain Sender Condition: NEW Country of Assembly: USA PROTECTIVE FIELD DATA Protective Field Height: 1,500 mm Resolution: 30 mm Scanning Range: 21 m Synchronization Method: Optical ELECTRICAL Supply Voltage: 24 VDC Operating Voltage Range: 19.2 VDC to 28.8 VDC Protection Class: Class III SAFETY DATA Safety Type: Type 4 Safety Integrity Level: SIL3 Safety Category: Category 4 Performance Level: PLe Mission Time: 20 Years FUNCTIONS Protective Operation: Yes Restart Interlock: Yes Beam Coding: Uncoded Fixed Blanking: Deactivated Floating Blanking: Deactivated EFI Communication: Supported INTERFACE DATA Configuration Connection: M8 Female 4-Pin Configuration Method: CDS Software Maximum Cable Length: 50 m CONSTRUCTION Housing Material: Aluminum Extruded Profile Housing Cross Section: 48 mm x 40 mm ENVIRONMENTAL Enclosure Rating: IP65 Operating Temperature: 0°C to +55°C Storage Temperature: -25°C to +70°C Humidity Range: 15% to 95% Non-Condensing Vibration Resistance: 5 g, 10 Hz to 55 Hz Shock Resistance: 10 g, 16 ms OPTICAL DATA Wavelength: 850 nm APPLICATION DATA Machine Safeguarding: Yes Robotic Cells: Yes Industrial Automation: Yes Packaging Equipment: Yes Personnel Protection: Yes Material Handling Systems: Yes
