Product Specifications:
-
Manufacturer: California Instruments
-
Model Number: 5001iX
-
Output Power: 5 kVA
-
Output Voltage Range: 0 – 300V AC / 0 – 400V DC
-
Frequency Range: 16 Hz – 5000 Hz
-
Phases: Single-Phase or Three-Phase Configurable
-
Power Source Type: Programmable AC/DC Power Supply with Analyzer
-
Interface: GPIB, RS-232, and optional LAN/USB
-
Display: Digital LCD with menu-driven control
-
Condition: Used
Key Features:
-
5kVA output capacity for high-load testing scenarios
-
Integrated power analyzer with harmonic distortion analysis
-
Programmable waveform generation for custom voltage and frequency simulation
-
Supports compliance testing for standards like MIL-STD-704, DO-160, IEC 61000
-
Remote control and automation-ready via multiple communication interfaces
Applications:
-
Aerospace and Military Power Testing
-
Power Electronics and Inverter Development
-
Compliance and EMC Testing Labs
-
R&D and Engineering Validation Environments
-
Simulating Global Power Conditions for Product Testing
