HEIDENHAIN ROD 426 5000 01 -03 ENCODER NEW WITH BOX

Product Specifications

• Model Number: ROD 426 5000 01-03

• Manufacturer: HEIDENHAIN

• Resolution: 5000 pulses per revolution (PPR)

• Signal Output: TTL (with differential line driver)

• Shaft Type: Solid shaft

• Shaft Diameter: 10 mm

• Housing Diameter: 58 mm

• Connection: Axial connector with mating cable interface

• Power Supply: 5V DC

• Mounting Type: Clamp flange

Key Features

• High-resolution 5000 PPR for precise speed and position feedback

• Durable and compact 58 mm housing suitable for tight installation spaces

• Solid shaft design for high mechanical stability

• TTL output with differential signaling for noise immunity

• Designed for seamless integration into CNC machines, robotics, and servo motors

Applications

• CNC machine tool feedback systems

• Robotics and automation controls

• Servo drive positioning

• Industrial motion control

• Printing and textile machinery requiring high-accuracy feedback
