Product Specifications
-
Manufacturer: HEIDENHAIN
-
Model Number: LC 493F/50M
-
ID Number: 557 644-01
-
Type: Linear Encoder
-
Measuring Length: 50 meters (50M version)
-
Output Signal: Absolute position feedback
-
Interface: EnDat 2.2 (digital bidirectional communication)
-
Accuracy Grade: High precision (± micrometer-level)
-
Scanning Technology: Optical with integrated scale
-
Housing: Sealed, aluminum extrusion for protection against dust and coolant
Key Features
-
Absolute measurement ensures immediate position feedback upon startup
-
Extremely high accuracy for critical machining and automation processes
-
Robust housing and sealing designed for harsh industrial conditions
-
Long measuring length capability (up to 50 meters)
-
Compatible with a wide range of HEIDENHAIN controllers and systems
Applications
-
CNC machine tools (milling, grinding, turning centers)
-
Precision automation systems
-
Semiconductor fabrication equipment
-
Coordinate measuring machines (CMMs)
-
Advanced robotics and metrology applications
