Product Specifications:
- Model Number: K2669-1
- Input Power: 380-575V, 3-phase, 50/60 Hz
- Rated Output: 350A @ 100% Duty Cycle
- Output Range: 5 – 420 Amps
- Processes Supported: Stick, TIG, MIG, Pulsed MIG, Flux-Cored, Gouging
- Power Source Type: Inverter-based
- Dimensions: 16.2 in (H) x 13.6 in (W) x 24.6 in (D)
- Net Weight: 77 lbs (35 kg)
Key Features:
- PowerConnect™ Technology: Automatically adjusts to input voltage for global compatibility
- Tribrid™ Power Module: Enhances durability and reduces maintenance with superior thermal performance
- Waveform Control Technology®: Allows precise control of arc characteristics for improved weld quality
- Ethernet Connectivity: Facilitates easy integration into automated systems and remote diagnostics
- User-Friendly Interface: Digital display and intuitive controls simplify setup and parameter adjustments
Applications:
- Heavy Fabrication and Manufacturing
- Automotive and Transportation Welding
- Construction Equipment Fabrication
- Shipbuilding and Offshore Structures
- Robotic and Automated Welding Systems
Alternative model numbers include: PowerWave I400 K2669, Lincoln K2669-1, PowerWave K2669-1, Lincoln Electric i400, K2669-1 PowerWave
Common misspellings include: Lincon Electric PowerWave, PowerWave i-400, PowerWave I4000, K26691, Power Wave i400
