▸ Key Features:
• Model 25T Accu-Coder incremental thru-bore encoder
• 1024 cycles per revolution (CPR) resolution
• 11 mm thru-bore shaft configuration
• Quadrature output with index pulse capability
• HV line driver output electronics
• 5 to 28 VDC operating voltage
• SG tether arm mounting configuration
• SMX 10-pin connector interface
• T1 extended temperature option
• S3 IP66 environmental sealing
• Opto-ASIC sensing technology
• Frequencies up to 1 MHz depending on application
▸ Applications:
• Motor-mounted feedback systems
• Vector motor control applications
• Industrial robotics
• Motion control systems
• Specialty machinery
• Web process control equipment
• Paper and printing machinery
• High-power motor installations
• Packaging equipment
• Industrial automation systems
▸ Alternative Model Numbers:
25T-11SG-1024NV1QHV-SMX-T1S3
25T-11SG-1024NV1QHV-SMK-S3
25T-11SG-4096NV1RHV-SMX
25H-11SG-1024NV1QHV-SMK-T4S3
Model 25T/H Encoder Series
▸ Common Misspellings or Phrasing:
25TC11SG1024NV1QHVSMXT1S3
Accu Coder 25TC
EPC 25TC Encoder
25T Incremental Encoder
25TC Thru Bore Encoder
Encoder Products 25TC
Heavy Duty Hollow Shaft Encoder
