▸ Key Features:
• Model 58TF Accu-Coder Pro incremental thru-bore encoder
• 58 mm industrial encoder platform
• 1024 CPR (Counts Per Revolution) resolution
• 5/8″ thru-bore configuration (Code 11)
• Line Driver (HV) output type
• Flexible SJ mounting pattern for large motor applications
• MK 8-pin M12 connector configuration
• S1 environmental sealing option (IP64)
• Operating voltage range of 4.75 to 30 VDC
• Maximum speed up to 6000 RPM
• Stainless steel shaft components and industrial-grade construction
▸ Applications:
• Motor control systems
• Motion feedback applications
• Conveyor systems
• Robotics and automation equipment
• Machine control systems
• Material handling equipment
• Elevator control systems
• Packaging machinery
• Process control installations
• OEM machinery and industrial automation
▸ Alternative Model Numbers:
58TF-11SJ-X1024B4HV-S-F03-S3
58TF-11SJ-X1024B4OC-S-MK
58TF-11SJ-X1024B3HV-S-MY-T6S4
58HF Series Hollow Bore Variants
58TP Programmable Encoder Series
▸ Common Misspellings or Phrasing:
58TF11SJX1024B3HVSMKS1
58TF Encoder
Accucoder 58TF
Encoder Products 58TF
EPC 58TF Encoder
Through Bore Encoder 1024 CPR
58TF-11SJ Encoder
