BROCK COMPTON WU-DA112MT-IE2 MOTORS NEW IN BOX

$350.00
Availability:

1 in stock
BRAND: BROOK CROMPTON MODEL: WU-DA112MT-IE2 CONDITION: new
SKU: IGAM0790038 Weight:999 LBS 999 lbs Freight (Item Must Ship Freight)

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Shipping Address

Product Information

Additional Information Required:

Information
Do you have a loading dock?
Do you have a forklift?
Financing
Subscribe to Emails

  • Motor Type: Three-phase asynchronous motor
  • Rated Power: 4 kW
  • Poles (Synch Speed): 4 poles (1500 RPM)
  • Full Load Speed: 1440 RPM
  • Voltage: 230/400 V
  • Frequency: 50 Hz
  • Connection: Delta/Star
  • Full Load Amps (FLA): 8.7/5.0 A
  • Enclosure: IP55
  • Mounting: B3 (IM 1001)
  • Insulation Class: F
  • Max. Ambient Temperature: +40°C
  • Min. Ambient Temperature: -20°C
  • Max. Temperature Rise: 80 K
  • Duty Type: S1 (Continuous)
  • Cooling Form: IC411 (TEFC)
  • Bearings: DE 6206 ZZ C3, NDE 6205 ZZ C3
  • Weight: 29.4 kg
  • Efficiency Class: IE2
  • Sound Pressure (1m): 54 dB(A)

This motor is designed for industrial applications and offers reliable performance with high efficiency.
