EATON DRY TYPE TRANSFORMER V48M28T75EE 75 KVA NEW

$2,750.00

Availability:

Out of stock

BRAND: EATON MODEL: V48M28T75EE CONDITION: new
SKU: IGAM0830003 Weight:575 LBS 575 lbs Freight (Item Must Ship Freight)

"*" indicates required fields

Phone

This field is for validation purposes and should be left unchanged.

First Name*

Last Name*

Email*

Phone*

Company Name*

Shipping Address

Country/Region*

Address*

City*

State*

Zip*

Product Information

Price

Brand

Model

SKU

Weight

Additional Information Required:

Information

Commercial

Residential

Do you have a loading dock?

Yes

Do you have a forklift?

Yes

Financing

Are you interested in Financing for your purchase?

Subscribe to Emails

Be the first to hear about iGAM exclusive offers, sales, markdowns and new arrivals.

About This Item

Product Specifications

Model: V48M28T75EE
Transformer Type: Dry-type, ventilated
Power Rating: 75 kVA
Phase: 3-phase
Primary Voltage: 480V
Secondary Voltage: 208Y/120V
Frequency: 60 Hz
Temperature Rise: 150°C
Windings: Copper
Enclosure: NEMA 2 (indoor use)
Efficiency: Meets DOE 2016 standards
Mounting: Floor-mounted

Key Features

Energy-efficient design with low losses and reduced operating costs
Copper windings for superior conductivity and long service life
Quiet operation ideal for commercial environments
NEMA 2 rated for secure indoor applications
UL listed and CSA certified for safety compliance
Minimal maintenance with no need for oil or liquid cooling

Applications

Commercial buildings and office complexes
Manufacturing plants and warehouses
Schools and institutions
Electrical rooms and utility areas
Data centers and technology infrastructure

Alternative model numbers include: Eaton 75kVA Transformer V48M28T75, Eaton V48M28T75CU, Cutler-Hammer V48M28T75EE, Eaton Dry Type Transformer 75 kVA, V48M28T75EE Copper
Common misspellings include: V48M2875EE, V48M28TT75EE, V48M28T75E, V48M28T75E3, V84M28T75EE
