The CTD D22-30 is a double miter saw manufactured by CTD Machines, specializing in industrial saws. It is known for its ability to cut two 45° miters simultaneously, which is particularly beneficial for the decorative art trade and similar applications.

key features and specifications:

– Blade Capacity: 12 inches (14-inch option available).
– Motor: 2 H.P. single or three-phase motor with a magnetic starter, providing 3450 RPM. The motor is fan-cooled and totally enclosed.
– Cutting Capacity: 4″ x 2.375″ with a 12-inch blade and 4″ x 2.5″ or 2″ x 6″ with a 14-inch blade.
– Precision: The saw heads are adjustable up to 3 degrees to ensure perfect miters, and it features adjustments for blade variation to minimize scrap.
– Construction: Built with precision-machined and ground iron castings for long-lasting accuracy. The spindle and pivot shafts are mounted on pre-loaded, sealed ball bearings.
– Safety: Features a lower rotating blade guard that pivots into the main stationary blade guard as the saw heads cut, enclosing the blade in the rest position.
